Single Swing Side Pulley With Stainless Steel Plates. 1 Alu. Sheave 76 MM
$ 41.16
- Description This stainless steel swing side snatch block features a lightweight 76 mm diameter deep groove aluminum sheave, with stainless steel plates that swing open to install rope. Sintered bronze bushing on stainless steel shaft provides 98% efficiency. Particularly useful for use when doubling the line, the rope cannot accidentally come out of the block. Also very useful to redirect a load or to pull upward in a hill. Use the steel locking carabiners to anchor to a polyester sling. Smaller and lighter than the PCA-1274 pulley. Ideal rope diameter: 10 mm. Specifications Minimum Breaking Strength: N/A Working Load Limit: 16 kN (1632 kg) Certification: – Material: Sides: Stainless Steel | Sheave: Aluminum Weight & Dimensions Weight: 0.69 kg Diameter: 76 mm Length: 17 cm Width: 11 cm Height: 11 cm Rope Minimum Diameter: 6 mm Maximum Diameter: 10 mm Warranty Other: 1 year Additional Information Not designed for steel cable. The Newton is the International System of Units unit for force; it is equal to the amount of net force required to accelerate a mass of one kilogram at a rate of one meter per second squared. The Working Load Limit (WLL) is the maximum load which should not be exceeded under any condition. The Minimum Breaking Strength (MBS) is observed during a destructive test. You should divide it by an appropriate safety factor.
