ANSI 300 Weld Neck Flange – Forged Carbon Steel ASME B16.5

Description Our class 300 weld neck flange delivers unmatched strength, resilience, and reliability to high-pressure piping systems. Additionally, our forged carbon steel weld neck flange features a long, tapered hub that enables it to maintain its structural integrity in extreme conditions with minimal stress development. Our ASME B16.5 Weld Neck Flange Specifications Made from Forged Carbon Steel material for lasting strength and resilience Pressure Rating: PN50 to withstand extreme conditions with ease Compliant to Dimensional standard ASME B16.5 to ensure effective performance Renowned Benefits of Our Forged Weld Neck Flange High-End Strength and Stress Distribution Our weld neck flange incorporates forged carbon steel in its buildup which allows it to deliver impactful performance under extreme conditions without affecting its structural integrity, thus ensuring lastingness for years. Leak-Free Performance With its raised face design and weld joint, our Class 300 weld neck flange provides secure sealing to piping connections, thus ensuring leak-tight performance every time. Standard Compliance Our forged carbon steel weld neck flange is designed in compliance with essential standards ASME B16.5, thus assuring effective performance in the harshest conditions with ease. Applications of Our Class 300 Weld Neck Flange Power generation systems Water treatment systems Industrial piping systems So, our ASME B16.5 weld on flange becomes your one-stop solution to have stronger piping connections for lasting times. ANSI B16.5 C300 Weld Neck Flange ITEM CODE IMPERIAL SIZE A B C D E F G H J BOLT SIZE RAISED FACE THICK. ¬†NUMBER OF HOLES APPROX. KG/PC 7602.06.25 1″ 123.9 88.9 33.5 50.9 62 17.5 34.5 20 54 5/8 1.6 ¬†4 1.8 7602.06.32 1. 1/4″ 135 98.4 N/A 63.6 65.1 19.1 42.2 20 63.6 5/8 1.6 4 2.06 7602.06.40 1. 1/2″ 155.6 114.3 48.3 73.1 68 20.7 49.5 22 69.9 5/8 1.6 ¬†4 3.2 7602.06.50 2″ 165.2 127 60.5 92.1 70 22.3 61.9 20 84.2 3/4 1.6 8 4.1 7602.06.65 2. 1/2″ 190 149.2 N/A 104.8 76.3 25.5 73.2 20 104.8 3/4 1.6 8 5.31 7602.06.80 3″ 209.6 168.2 88.9 127.1 79 28.6 90.6 22 117.5 3/4 1.6 8 6.8 7602.06.94 4″ 254.1 200 114.4 157.2 86 31.8 116 22 146.1 3/4 1.6 8 11.4 7602.06.95 5″ 279.5 234.9 141.3 185.8 98.5 35.0 143.7 22 177.9 3/4 1.6 8 15.12 7602.06.96 6″ 317.6 269.8 168.4 216 98 36.5 170.6 22 206.4 3/4 1.6 12 19.1 7602.06.98 8″ 381 330.2 202.7 269.8 111 41.1 219.2 26 260.4 7/8 1.6 12 30.4
